JH-Nc90-3d-Sl Pulling Type 3d Cnc Laser Pipe Cutting Machine

Introducing the JH-NC90-3D-SL PULLING TYPE 3D CNC LASER PIPE CUTTING MACHINE, a solution engineered to redefine precision pipe cutting. With its innovative features and unparalleled performance, this machine offers a seamless combination of efficiency, versatility, and safety.

Performance:
Equipment Specifications:
- Borehole Size (mm)：88mm
- Exterior Dimensions (Length * Width * Height(mm):8900*1900*2200
- Operating Temperature (℃):0-40

Processing Range:
- Servo Fixed-length Shaft Stroke (mm):10-1500
- Pulling Shaft Single Pull Length (mm):1300
- Continuous Pulling Length of Pulling Shaft (m):9
- Diameter Range for Rotating Shaft Processing (mm):6mm-86mm
- Cutting Groove Width (mm):0.08-0.2

Stroke Range:
- X-axis Stroke (mm):150
- Y-axis Stroke (mm):1300
- Z-axis Stroke (mm):100

Repetitive Positioning Accuracy/Speed:
- Repetitive Positioning Accuracy of X/Y-axis (mm):0.02
- Repetitive Positioning Accuracy of B-axis (arc minute):≤5
- Maximum Rotational Speed of B-axis (RPM):800

Repetitive Positioning Accuracy/Speed:
- Maximum Acceleration of X/Y-axis:1.5G
- Maximum Idle Speed of X-axis (m/min):30
- Maximum Idle Speed of Y-axis (m/min):30

Loading Parameters: Loading Length (m):6
Unloading Parameters: Tail Length (mm):≤30
Operating Voltage (V):380
Total Machine Weight (kg):2622
Equipment Power (kw):13.5

Model Advantages:
1. Simple and Intuitive Operation:
The JH-NC90-3D-SL is designed with user-friendliness in mind, ensuring that operators can quickly grasp its functionality and operate it with ease. Its intuitive interface streamlines the cutting process, reducing the learning curve and productivity.

2. High Efficiency:
Experience unparalleled productivity with the JH-NC90-3D-SL. Equipped with advanced laser cutting technology, this machine delivers high-speed and precise cutting, allowing for rapid production without compromising on quality.

3. Exceptional Stability:
Built to withstand the demands of industrial environments, the JH-NC90-3D-SL offers exceptional stability during operation. Its robust construction ensures consistent and reliable performance, minimizing downtime and output.

4. Energy Efficiency and Material Savings:
The JH-NC90-3D-SL is designed to be energy-efficient, reducing power consumption without compromising on performance. Additionally, its precise cutting capabilities minimize material waste, resulting in significant cost savings over time.

5.3D Cutting Capability:
With its advanced 3D cutting technology, the JH-NC90-3D-SL offers unparalleled versatility in cutting pipes from various angles and orientations. Whether you need intricate bevel cuts or complex geometries, this machine delivers precise results with ease.

Types of Cutting Pipes:
The JH-NC90-3D-SL is capable of cutting a wide range of pipe types, including:
- Round Tubes: Perfect for applications requiring cylindrical components.
- Square Tubes: Ideal for structural frameworks and architectural elements.
- Rectangular Tubes: Suited for a variety of applications, including frames and supports.

Standard Collocation:
1. Dual System Control:
This machine comes equipped with two control systems for added flexibility and convenience. The large-screen Weihong system offers intuitive control and monitoring, while the XINjie system PLC with a small screen provides additional functionality and versatility.
2. Loading Rack System:
The machine is complemented by the XINjie loading rack system PLC, facilitating efficient material handling and loading. With its user-friendly interface and advanced automation features, the loading rack system ensures smooth workflow integration and optimized productivity.

Optional Items:
1. Square Tube Automatic Feeding Rack:
Enhance workflow efficiency with the optional square tube automatic feeding rack, streamlining material handling and reducing manual labor.
2. Copper Tube Slag Suction System: Opt for the optional copper tube slag suction system, equipped with a Vortex fan, to effectively remove slag and debris during cutting, ensuring clean and precise results.
3. Optional Blanking Conveyor Belt: Choose the optional blanking conveyor belt for seamless material handling and disposal, further optimizing your production process.
4. Six-Wheel Drive Feeding Table Widening Rack: For applications involving thick-walled pipes or pipes with oil walls, the six-wheel drive feeding table widening rack offers enhanced stability and precision, ensuring smooth and precise cutting even in challenging conditions.

Applications:
- Automotive: Precision cutting of exhaust pipes and chassis components.
- Aerospace: Fabrication of intricate components for aircraft structures and systems.
- Construction: Efficient production of pipe components for building frameworks and infrastructure.
- Manufacturing: Versatile cutting solutions for machinery components and equipment.
- Energy: Cutting and shaping pipes for pipelines and renewable energy systems.

Experience the future of pipe-cutting technology with the JH-NC90-3D-SL. Unlock new levels of efficiency, precision, and versatility in your operations.
